The time has come to replace your hydraulic cylinder. Where do you begin? Correctly measuring and sizing your hydraulic cylinder can alleviate issues that can arise when replacing your cylinder. Learn about what cylinder components need to be measured and understand how to measure them correctly with our simple measurement guide.

Common Measurements for Hydraulic Cylinders

Hydraulic cylinder measurements should include primary component measurements. Tools to measure hydraulic cylinder components include a tape measure and/or calipers.

Primary Components for Hydraulic Cylinder Measurement

  • Retracted length of a hydraulic cylinder
    • Measurement is the center of a pin to center of a pin when the cylinder is fully retracted
  • Extended length of a hydraulic cylinder
    • Measurement is the center of a pin to center of a pin fully extended
  • Stroke length
    • Measurement is the extended length of a hydraulic cylinder minus the retracted length
  • Bore diameter
    • Measure the outside diameter of the cylinder and subtract the tubing wall thickness
    • Standard bore sizes range from 1.5” up to 6” bore diameters
  • Rod diameter
    • Measurement is primarily done with a caliper
  • Base mount pin size
  • Rod mount pin size
  • Base and rod mount dimensions
  • Determine port size and style

Note that your hydraulic cylinder type can be single or double-acting and can be welded or telescopic. Knowing which type of hydraulic cylinder you are replacing is important for accurate cylinder replacement.

WELDED ROD HYDRAULIC CYLINDER

Welded Rod Hydraulic Cylinder Diagram

TELESCOPIC HYDRAULIC CYLINDER



Why Proper Measurement is Important for Replacement Hydraulic Cylinders

Save yourself time and money by measuring your hydraulic cylinder before you need to replace it. Having the measurements ready ahead of time can ensure your replacement cylinder is not only correctly measured for your replacement, but also keeps your shop organized for quick replacement turnaround.

Check Out Our Hydraulic Cylinder Measurement Guide

Watch our hydraulic cylinder measurement guide and learn more about the proper technique for measuring hydraulic cylinders.
